5P8362

The 5P8362 is a 1-1/4" countersunk plow bolt with 1-1/4"-7UNC threading, one of the essential fasteners in ground engaging equipment. At 127 mm (5") overall length, this Grade 10.9 fastener is manufactured by AzuLong Wear Parts from 40Cr Alloy Steel with black oxide finish. Used to mount cutting edges, wear plates, and ground engaging tools on Caterpillar ground engaging equipment including motor grader blades, wheel loader cutting edges, bulldozer end bits, and scraper cutting edges.

Grade 10.9, Strength & Performance

Grade 10.9 (Class 10.9) plow bolts provide a tensile strength of approximately 1040 MPa and yield strength of 940 MPa. The higher strength rating makes these bolts essential for heavy-duty cutting edge and ground engaging equipment where bolts must resist shearing forces from rock and compacted material. Manufactured from 40Cr alloy steel with controlled heat treatment to achieve consistent mechanical properties.

1-1/4" Diameter, Size & Application

The 1-1/4" diameter is among the largest standard plow bolt sizes, specified for mining-class equipment, large bulldozers, wheel loaders, and dragline buckets. The high shear area of the 1-1/4" shank handles the extreme forces generated by equipment weighing 50+ tons.

Equipment Compatibility

The countersunk head sits flush with the cutting edge surface, keeping the bolt head out of the material flow path where it would wear fast. Contact rocky@azulong.com or WhatsApp +86-13777046128 for pricing and availability.

• CAT Motor Graders (120, 140, 160)
• CAT Wheel Loaders (950, 966, 980)
• CAT Bulldozers (D6, D7, D8)
• CAT Scrapers (613, 621, 631)
